CUBE Bikes Aim SL

CUBE Bikes Aim SL
  • Color: Black 'n Orange
  • Color: Grey 'n Blue 'n Red
$879.99 - $1,099.00
Color: Black 'n Orange
Size: Select size
Wheel Size: Select wheel size
Please select options Unavailable


This is a bike for riders looking to broaden their trail-riding horizons. The Suntour XCM suspension fork, with 100mm of fatigue-reducing travel for better comfort and control, has the convenience of a remote lockout. Shimano's powerful, safe hydraulic disc brakes mean you can stop in any weather and on any road or trail surface. And the superbly slick-shifting Shimano gears put the right ratio for any riding scenario just a click away.

Wheel size:
Sizes X-Small – Medium: 27.5-inch
Sizes Large – XX-Large: 29-inch


Frame Aluminum Lite, AMF, Internal Cable Routing, Easy Mount Kickstand Ready
Fork SR Suntour XCM RL Disc, 100mm, Remote Lockout
Rims CUBE ZX20, 32H, Disc
Hubs Front: Shimano HB-TX505, QR, Center Lock
Rear: Shimano FH-TX505, QR, Center Lock
Tires Schwalbe Smart Sam, Active, 2.25"
Crankset Shimano FC-MT101, 40x30x22T, 175mm
Shifters Shimano SL-M2010, Rapidfire-Plus
Front Derailleur Shimano FD-M3000, Top Swing, 31.8mm Clamp
Rear Derailleur Shimano RD-M3100, 9-Speed
Cassette/Freewheel Shimano CS-HG201-9, 11-36T
Chain KMC X9
Brakes Shimano BR-MT200, Hydr. Disc Brake (160/160)
Handlebars CUBE Rise Trail Bar, 680mm
Tape/Grips CUBE Performance Grip
Stem CUBE Performance Stem Pro, 31.8mm
Headset CUBE FPH863, Semi-Integrated
Seatpost CUBE Performance Post, 27.2mm
Saddle Natural Fit Venec Lite

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Black 'n Orange / X-Small / 27.5-inch 4054571321459 40150014
Black 'n Orange / Small / 27.5-inch 4054571321466 40150016
Black 'n Orange / Medium / 27.5-inch 4054571321473 40150017
Black 'n Orange / Large / 29-inch 4054571321480 40150019
Black 'n Orange / X-Large / 29-inch 4054571321497 40150021
Black 'n Orange / XX-Large / 29-inch 4054571321503 40150023
Grey 'n Blue 'n Red / X-Small / 27.5-inch 4054571321510 40151014
Grey 'n Blue 'n Red / Small / 27.5-inch 4054571321527 40151016
Grey 'n Blue 'n Red / Medium / 27.5-inch 4054571321534 40151017
Grey 'n Blue 'n Red / Large / 29-inch 4054571321541 40151019
Grey 'n Blue 'n Red / X-Large / 29-inch 4054571321558 40151021 210000009549
Grey 'n Blue 'n Red / XX-Large / 29-inch 4054571321565 40151023 210000009551
