Details
Jump on the fun-igniting E-Hatchet Tour and see where its wheels will take you. With unparalleled capability, the right amount of electric assistance, and the ability to keep up with your fittest riding partner, the E-Hatchet Tour multiplies your opportunities. Inspired by an all-road DNA, this ePowered gravel toreador will master the steepest hills on your favorite countryside loop. Featuring a lightweight Mahle X30 hub-drive system providing 45Nm of torque paired with a 237Wh battery, this aluminum masterpiece delivers just what you need.?
MAHLE X30 ELECTRIC SYSTEM
Technologies and advancements in the E-Gravel segment have evolved significantly, and we can confidently say we've done our homework to bring the all-new E-Hatchet Tour to life. The bulky mid-drive motor and external battery have now been replaced by a discreet hub-drive motor system. Powered by the latest model from motor manufacturer MAHLE, the X30, this lightweight and compact system delivers 45 Nm of torque and 250 W of power. Why going with a hub-drive design? It helps reduce weight, maintain a sleek frame appearance, and ensures easy maintenance.
INTERNAL 237Wh BATTERY
Minimal profile, seamlessly integrated, and compact – these are the defining features of the MAHLE iX2 237 Wh battery powering the E-Hatchet Tour. Weighing just 1500 grams, this lightweight energy solution delivers an efficient 237 watt-hours of reliable power, that tallies up to 90 kilometers of range, wherever your adventures take you.
Specs
| Frame | Aluminum Optimum R03 |
|---|---|
| Fork | Carbon OSC |
| Headset | FSA No.55R | Internal Routing |
| Rims | V2 Comp db | 24mm inner |
| Hubs | (f) Formula Disc | Sealed bearings | TA 12x100mm / (r) Mahle X30 Drive Unit |
| Spokes | Stainless 14G |
| Tires | WTB Vulpine | 700x40c |
| Crankset | Shimano GRX610 | 12s | 46/30T |
| Bottom Bracket | Mahle X30 TCS BB86 Torque Sensor |
| Chain | Shimano M6100 | 12s |
| Rear Cog(s) | Shimano 105 | 12s | 11-34T |
| Handlebars | V2 Pro | B:31.8mm | R:70mm | D:125mm | 16° FLARE |
| Tape/Grips | Super Soft |
| Stem | V2 Pro | B:31.8mm | 6° |
| Brakes | Shimano GRX610 | 2s / Shimano RT-56 | 160mm | 6 Bolts |
| Seat Binder | Devinci | 31.8mm |
| Rear Derailleur | Shimano GRX820 | 12s |
| Front Derailleur | Shimano GRX820 | 2s |
| Drive Unit | Mahle X30 Drive Unit | 250W | 45Nm |
| Battery | Mahle iX2 | 36V | 237Wh |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Granite Green / Small | |||
| Granite Green / Medium | 883385256589 | FE25085311 | 210000013130 |
